It is a material with good mechanical properties
ABS has good toughness and impact resistance, which can print strong and durable parts.
It has a high thermal deformation temperature and can be used in some outdoor and high temperature applications.
Example Application areas
-Machinery
- Forms
- Toys
-Car
-Electronic products
Printed Models
Parameter Information
| Filament Properties Table
|
|
| 3D PRINTING FILAMENT |
ABS |
| Density (g/cm3) |
1.04 |
| Heat Distortion Temperature (℃, 0.45 MPa) |
78 |
| Melt Flow Index (g/10 min) |
12(220℃/10kg） |
| Tensile strength (MPa) |
43 |
| Elongation at break (%) |
22 |
| Flexural Strength (Mpa) |
66 |
| Flexural Modulus (MPa) |
1177 |
| IZOD Impact strength (kJ/㎡) |
29 |
| Abrasion resistance |
8/10 |
| Printing |
8/10 |
| Recommended print parameters
|
|
| Extruder temperature (℃) |
230 – 270℃ Recommended temperature: 240℃ |
| Bed temperature (℃) |
95 – 110°C |
| Fan speed |
0% |
| Print speed |
40 – 100mm/s |
| Heated bed |
Necessary |
| Recommended building surfaces |
Heat resistant tape, PVP solid glue, Printer's included mat |
| Functions
|
|
| Flexible |
—— |
| Elastic |
—— |
| Shock resistant |
√ |
| Soft |
—— |
| Composite |
—— |
| UV resistant |
—— |
| Water resistant |
—— |
| Dissoluble |
—— |
| Heat resistant |
√ |
| Chemically resistant |
—— |
| Fatigue resistant |
—— |
| Needs drying |
—— |
| Heated bed required |
√ |
| Printing recommendation |
Print in a closed chamber, minimize the angle of the overhang structure on the model |
Notes
The shrinkage of ABS material is high when printing. So a chamber to print the ABS filament is required.
Storage
How to store the filament:
1. If you are going to leave your printer inactive for more than a couple of days, please retract the filament to protect the printer nozzle.
2. To extend the life of your filaments, put the release filament back into the original vacuum bag and store it in a cool, dry place after printing.
3. When storing your filament, please feed the loose end through the holes on the edge of the filament roll to avoid winding, so that it will feed properly the next time you use it.
