Ender-3 V3 KE
The Creality Ender-3 V3 KE is an upgraded version of the Ender-3 V3 SE with improvements such as higher print speed, wider filament compatibility and a 4.3-inch color touchscreen. The machine is equipped with a CR-Touch Auto Leveling Sensor and a wire strain gauge that makes leveling and calibrating the Z-offset a breeze.
Extraordinary print speed
The printer can print at a speed of 500 mm/s, which means that a Benchy can be printed in about 15 minutes.
A-axis linear rail, extremely smooth movement
The precise linear rail on the X axis has a rod with ball bearings, making every movement precise, steady and frictionless (0.04 coefficient of friction). It is built in heavy-duty steel and stays like new even after prolonged use.
Superior hotend to meet bigger challenges
60W ceramic heater that can melt the filaments completely for high speed printing; heatbreaks in bimetal (copper + titanium alloys) that effectively prevent thermal creep; nozzle in copper that enables printing at 300 °C.
Double fans for fast cooling of models
Each side of the print head has a cooling fan. Together, they cool the newly printed part quickly and evenly. Now your prints are always in good condition.
Smart user interface at your fingertips
Responsive touch interface with an intuitive tab bar; Smart self-test for Z-offset, auto-leveling and more at the touch of a button; Real-time model, preview and live moving graphics for print parameters.
The fun goes beyond the limits of space with LAN printing and cloud printing. Every aspect of your 3D printer can be controlled from a computer (with Creality Print) or a phone (with Creality Cloud APP) via WiFi. With multiple printers online, you can manage them efficiently as a print farm.
More filaments to print with
Ender-3 V3 KE can handle filaments of Hyper PLA, PETG, ABS, TPU(95A) and ASA. Just choose the right filament to print the object, part or product you like. Ender-3 V3 KE delivers faster and better prints with Creality Hyper PLA.
Technical Specifications
|
Construction and technical details
|
|
|
Usable nozzles Typ
|
K1
|
|
Usable wire diameter
|
1.75 mm
|
|
Temperature in the nozzle Max
|
300 ºC
|
|
Open filament system
|
Yes
|
|
Extruder Type
|
Direct drive
|
|
Recommended print speed Max
|
500 mm/s (
|
|
Print area
|
220mm x 220mm x 240mm
|
|
Building plate temperature max.
|
100 ºC
|
|
The surface of the building plate
|
Adhesive sheet
|
|
The material of the building plate
|
Flexible steel plate
|
|
Bracket for building plate
|
Magnetic
|
|
System for setting the building plate
|
Automatic - CRTouch
|
|
The construction chamber during the process
|
Open
|
|
Extruder Quantity
|
1
|
|
|
|
Installation space/requirements
|
|
|
Total mass
|
433mm x 366mm x 490mm
|
|
Total weight
|
7.8 kg
|
|
Maximum power consumption
|
350W
|
|
Voltage
|
AC: 100 V240 V (50-60 Hz)
|
|
|
|
Equipment
|
|
|
Hepa filter
|
No
|
|
Filament Sensor - End
|
Yes
|
|
Fail safe in case of power failure
|
Yes
|
|
Touch screen
|
Yes
|
|
|
|
Connection
|
|
|
USB port
|
Yes
|
|
Ethernet port
|
Yes
|
|
Cloud control
|
Yes
|
|
|
|
Accuracy
|
|
|
Stock height
|
0.1 - 0.35 mm
|
