K1 - King of Speed
The K1, with its amazing speed, will rekindle people's enthusiasm for 3D printing. The fast speed reduces printing time and increases efficiency, and it uses less energy for the same output, making it more environmentally friendly. Most importantly, it focuses on the pure joy of creating.
Fast, in an epic way
Crazy 600mm/s. The K1 is 12 times faster than a standard FDM 3D printer. Sit back to experience the breathtaking speed.
Always print at full speed
With an acceleration of 20000 mm/s², the K1 increases to 600 mm/s in just 0.03 seconds, providing full speed for 90% of the printing time.
Quick setup for speed
The K1 combines the smooth Core XY with a 190g lightweight print head for less movement inertia. Smooth and fast.
32mm³/s flow at full blast
New ceramic heater, which surrounds the entire hotplate. It heats up to 200℃ in 40 seconds and melts the filament instantly. Double gear direct extruder, providing 50N strong extrusion force. Hotend with a titanium alloy heat switch and a copper alloy nozzle, which works brilliantly in up to 300℃.
Model cooling with double fans
A large fan on the print head with air channels cools the model directly. An 18 W extra fan in the build chamber also improves the cooling effect.
The model hardens before it can be laced and warped. It enables unsupported bridges and overhangs.
Creality Print 4.3 with Speed Genes
The latest self-developed slicer Creality Print 4.3 contains many presets and streamlines the slicing process in three simple steps. Even better, it supports high-speed printing with variable line width, arc path and so on.
Speedy Creality OS and hardware
K1 uses the smart operating system Creality OS. It has a simple user interface and synchronizes data and commands with computer, phone, the cloud and add-on modules. The fast dual-core 1.2 GHz CPU easily drives high-speed printing. The 8G ROM stores up to 400 model files and enables fast writing and reading.
K1 Features:
-
Fast heating of the heating bed: The aluminum alloy heating plate spreads the heat evenly and quickly. It reaches 60 °C in just 180 seconds.
-
Flexible build plate: It is sticky and heat resistant and works well with a wide variety of filaments. The finely frosted surface makes the model base nice and smooth. Bendable for quick print removal.
-
One-press self-test: With one press, the K1 can self-test the extruder, heating bed, camera (optional), fan, leveling, etc. Any deviations detected will be shown on the display. So users can continue safely without any problems.
-
Hands-free Auto Leveling: A number of voltage sensors are embedded in the heating bed to generate a precise leveling grid. The whole process happens on its own after the printing starts. You don't have to lift a finger or pay any attention.
Connected and worry-free control
K1 can print via USB device or WiFi. With a network connection, K1 can be controlled or monitored* remotely from Creality Print or Creality Cloud APP/WEB. Cluster control is also allowed when many K1 printers are online. When printing is complete or abnormal, a message is sent to your phone or computer. No more careful monitoring.
Stick to the speed challenge
The K1's cast aluminum alloy frame is CNC machined to be precise and rigid. It enables stable printing at high speed. And the print quality is excellent all the time.
No ringing at high speed
A G-sensor in the print head measures the resonant frequencies of high-speed printing and automatically adjusts the printer to reduce them. No more ghosting or ringing on the printout.
Delicate texture without Z-bend
The upgraded Z-axis with more accurate positioning reduces Z-banding effectively. Texture has never been so subtle.
Technical Specifications
|
Construction and technical details
|
|
|
Usable nozzles Typ
|
K1
|
|
Usable wire diameter
|
1.75 mm
|
|
Temperature in the nozzle Max
|
300 ºC
|
|
Open filament system
|
Yes
|
|
Extruder Type
|
Direct drive
|
|
Print area
|
220mm x 220mm x 250mm
|
|
Building plate temperature max.
|
100 ºC
|
|
The surface of the building plate
|
adhesive sheet
|
|
The material of the building plate
|
Flexible steel plate
|
|
Bracket for building plate
|
Magnetic
|
|
System for setting the building plate
|
automatic
|
|
The construction chamber during the process
|
Open or closed
|
|
Extruder Quantity
|
1
|
|
|
|
Installation space/requirements
|
|
|
Total mass
|
355mm x 355mm x 480mm
|
|
Total weight
|
13.2 kg
|
|
Maximum power consumption
|
350W
|
|
Voltage
|
AC: 100 V240 V (50-60 Hz)
|
|
|
|
Equipment
|
|
|
Hepa filter
|
No
|
|
Filament Sensor - End
|
Yes
|
|
Fail safe in case of power failure
|
Yes
|
|
Touch screen
|
Yes
|
|
Camera
|
Yes
|
|
|
|
Connection
|
|
|
USB port
|
Yes, 1 x USB-A
|
|
Ethernet port
|
Yes
|
|
Wi-Fi
|
Yes
|
|
Cloud control
|
Yes
|
|
|
|
Accuracy
|
|
|
Stock height
|
0.1 - 0.35 mm
|
|
|
|
Delivery
|
|
|
Delivery box
|
415mm x 415mm x 550mm
|
|
Transport weight
|
15.4 kg
|
