Fast, in an epic way
Crazy 600mm/s. The K1 series is 12 times faster than a standard FDM 3D printer. Sit back for the thrill of breathtaking speed.
Quick setup for speed
K1 Max combines the smooth Core XY with a 190 g lightweight print head for less movement inertia. Smooth and fast.
32mm³/s flow at full blast
New ceramic heater, which encloses the entire hot end. It heats up to 200℃ in 40 seconds and melts the filament instantly. Double gear direct extruder, providing 50N strong extrusion force. Hotend with a titanium alloy heat switch and a copper alloy nozzle, which works brilliantly up to 300℃.
Model cooling with double fans
A large fan on the print head with air channels cools the model directly. An 18 W extra fan in the build chamber also improves the cooling effect.
The model hardens before it can be laced and warped. It enables unsupported bridges and overhangs.
Creality Print 4.3 with Speed Genes
The latest self-developed slicer Creality Print 4.3 contains many presets and streamlines the slicing process in three simple steps. Even better, it supports high-speed printing with variable line width, arc path and so on.
Maximum capacity, efficient use of space
The K1 Max has a 300x300x300 mm build volume, which is perfect for rapid prototyping or verification of designs. It also has a high build volume to printer size ratio of 25.5%. The K1 Max is the most size-efficient FDM 3D printer in its class.
AI-assisted Carefree Printing
- AI LiDAR
- AI camera
- Creality OS
- Control of multiple printers
AI LiDAR takes care of the first layer
Still worried about the first layer? Leave it all to AI LiDAR in the K1 Max. LiDAR with a resolution of 1 μm scans the first layer on its own. It pauses printing and notifies you immediately if something goes wrong.
AI camera keeps a watchful eye
K1 Max uses an AI camera to monitor spaghetti bugs, foreign objects, debris, etc. It alerts you when an error occurs. It also supports real-time monitoring and creates time-lapses for sharing.
Creality OS
K1 Max uses the smart operating system Creality OS. It has a simple user interface and synchronizes data and commands with the computer, phone, cloud and add-on modules. The fast dual-core 1.2 GHz CPU easily drives high-speed printing. The 8G ROM stores up to 400 model files and enables fast writing and reading.
Intelligent support for your print farm
When K1 Max is connected via WiFi or RJ45 Ethernet port to LAN or Internet, you can monitor and control the print from a computer or phone using Creality Print software or Creality Cloud. Even better, when multiple K1 Max printers are online, they can be easily clustered or grouped for volume production.
Rigid frame, stable quality
The K1 Max cast aluminum alloy unit frame is CNC machined to be precise and rigid, enabling stable high-speed printing. And the print quality is excellent all the time.
Delicate texture without Z-bend
The upgraded Z-axis with more accurate positioning reduces Z-banding effectively. Texture has never been so subtle.
Technical Specifications
|
Construction and technical details
|
|
|
Usable nozzles Typ
|
K1
|
|
Usable wire diameter
|
1.75 mm
|
|
Temperature in the nozzle Max
|
300 ºC
|
|
Open filament system
|
Yes
|
|
Extruder Type
|
Direct drive
|
|
Print area
|
300mm x 300mm x 300mm
|
|
Building plate temperature max.
|
120 ºC
|
|
The surface of the building plate
|
adhesive sheet
|
|
The material of the building plate
|
Flexible steel plate
|
|
Bracket for building plate
|
Magnetic
|
|
System for setting the build plate
|
automatic
|
|
The construction chamber during the process
|
Open or closed
|
|
Extruder Quantity
|
1
|
|
|
|
Installation space/requirements
|
|
|
Total mass
|
435mm x 462mm x 526mm
|
|
Total weight
|
18 kg
|
|
Maximum power consumption
|
1000W
|
|
Voltage
|
AC: 100 V240 V (50-60 Hz)
|
|
|
|
Equipment
|
|
|
Hepa filter
|
Yes
|
|
Filament Sensor - End
|
Yes
|
|
Fail safe in case of power failure
|
Yes
|
|
Touch screen
|
Yes
|
|
Camera
|
Yes
|
|
|
|
Connection
|
|
|
USB port
|
Yes, 1 x USB-A
|
|
Ethernet port
|
Yes
|
|
Wi-Fi
|
Yes
|
|
|
|
Accuracy
|
|
|
Stock height
|
0.1 - 0.35 mm
|
|
|
|
Delivery
|
|
|
Delivery box
|
508mm x 508mm x 608mm
|
|
Transport weight
|
23 kg
|
