PETG is a material with water resistance, chemical resistance and high toughness. It is tougher than ABS
The printed product has a transparent and smooth surface. It is easy to print as PLA without a temperature chamber.
Example Application areas
-Household appliances
- Toys
- Paper products
-Electronic products
Printed models
Product Details
Parameter Information
| Filament Properties Table
|
|
| 3D PRINTING FILAMENT |
PETG |
| Density (g/cm3) |
1.27 |
| Heat Distortion Temperature (℃, 0.45 MPa) |
64 |
| Melt Flow Index (g/10 min) |
20（250℃/2.16kg) |
| Tensile strength (MPa) |
52.2 |
| Elongation at break (%) |
83 |
| Flexural Strength (Mpa) |
58.1 |
| Flexural Modulus (MPa) |
1073 |
| IZOD Impact strength (kJ/㎡) |
4.7 |
| Abrasion resistance |
8/10 |
| Printing |
9/10 |
| Recommended print parameters
|
|
| Extruder temperature (℃) |
230 – 250℃ Recommended temperature 240℃ |
| Bed temperature (℃) |
75 – 90°C |
| Fan speed |
100% |
| Print speed |
40 – 100mm/s |
| Heated bed |
Necessary |
| Recommended building surfaces |
PVP glue, PEI, Printer's supplied mat |
| Functions
|
|
| Flexible |
—— |
| Elastic |
—— |
| Shock resistant |
—— |
| Soft |
—— |
| Composite |
—— |
| UV resistant |
—— |
| Water resistant |
√ |
| Dissoluble |
—— |
| Heat resistant |
—— |
| Chemically resistant |
√ |
| Fatigue resistant |
√ |
| Needs drying |
—— |
| Heated bed required |
√ |
| Printing recommendation |
Dry at 65℃/>3h |
Notes
-A fan speed of 100% can be used to ensure the best possible surface when printing PETG.
-If you are looking for a strong print, disable the fan or set the fan speed to 0% to allow the print to adhere well between layers.
-Reduce the print speed to 60mm/sec is recommended.
Storage
How to store filament:
1. If you are going to leave your printer inactive for more than a couple of days, please retract the filament to protect the printer nozzle.
2. To extend the life of your filaments, put the release filament back into the original vacuum bag and store it in a cool, dry place after printing.
3. When storing your filament, please feed the loose end through the holes on the edge of the filament roll to avoid winding, so that it will feed properly the next time you use it.
