Sunlu High-Speed PLA
Sunlu High-Speed PLA
SUNLU's High Speed PLA is a PLA material specially designed for high speed printing. Compared to standard PLA, this HighSpeed PLA can achieve a 300% higher speed of up to 600 mm/s. Material fluidity has also increased by an incredible 500% to ensure smooth extrusion and prevent possible nozzle clogging.
- 500% higher fluidity
- 300% higher speeds
- Good antistatic properties
20+ in stock
Dela
Sunlu high speed PLA filament
SUNLU's High Speed PLA is a PLA material specially designed for high speed printing. Compared to standard PLA, this High Speed PLA can achieve a 300% higher speed of up to 600 mm/s. The fluidity of the material has also increased by an incredible 500% to ensure smooth extrusion and prevent possible nozzle clogging.
More time and energy saving
Print quality at 0-100mm/s is superior to regular PLA, providing smoother surfaces and better overhang. With overhang angles of less than 70° that do not require support, this filament significantly reduces print time and material waste. It enables fast printing at a low temperature of 180-195℃, saving both time and energy.
500% improved buoyancy
No clogging even at high-speed prints of ≥250mm/s, ensuring smooth material flow.
Improved heat dissipation
The heat dissipation capacity of High Speed PLA has increased by 180%, providing faster cooling under the same conditions and enabling fast printing without material build-up.
High crystallization temperature
High Speed PLA has a fast cure rate, which improves fast printing and draping performance. Excellent air cooling of the printer can eliminate the need for support for drape angles less than 70°.
Low shrinkage rate
The filament has low shrinkage, which reduces the risk of cracks during fast printing and produces smooth surfaces.
Nicely oriented
High Speed PLA has a uniform wire diameter and enables fast, knot-free printing, resulting in smooth and smooth material output.
Technical Specifications
Basic Information |
|
Filament type |
PLA |
Diameter |
1.75 mm |
Weight |
1.00 kg |
Length |
330 m |
Paint |
White |
|
|
Parameters for printing |
|
Recommended min print temperature |
205 ºC |
Recommended maximum pressure temperature |
215 ºC |
Recommended min. bed temperature |
50 ºC |
Recommended maximum bed temperature |
60 ºC |
Recommendation My print speed |
0 mm/s |
Recommendation Max print speed |
250 mm/s |
Recommendation Max fan speed |
100% |
Recommended indentation Max |
5 mm |
Generally |
|
Specific gravity |
1.26 g/cm3 ASTM D792 |
Shrinkage in shape |
0.2 ASTM D955 |
Specific volume resistivity |
2.90E+15 ASTM D257 |
Temperature |
|
Vicat softening temp. |
54 °C ASTM D1525 |
Heat deflection temperature |
57.3 °C ASTM D648 |
Traction force |
|
Tensile strength |
54.1 MPa ASTM D638 |
Traction module |
3282 MPa ASTM D638 |
Extension |
|
Extension in case of breach |
13.9% ASTM D638 |
Bendability |
|
Bending strength |
75.2 MPa ASTM D790 |
Flexural modulus |
2357 MPa ASTM D790 |
Other |
|
Impact resistance |
5.9 KJ/m2 ISO 180 |
